Selectivity, also known as protective device coordination, is a fundamental concept in electrical power system design, especially in environments like data centres where continuous operation is critical. Selectivity ensures that, in the event of an electrical fault, only the protective device nearest to the fault (such as a fuse or circuit breaker) will operate to isolate the affected portion of the system. This prevents a localised fault from causing a complete shutdown of the entire electrical system, thereby minimising downtime and avoiding unnecessary disruption to other parts of the network.
In a data centre, electrical reliability is of utmost importance due to the need for uninterrupted power to servers, cooling systems, and networking equipment. Therefore, achieving proper selectivity in the protective devices used in the power distribution system is crucial.
In this blog post, Senior Electrical Engineer at Future-tech, Atousa Zaeim, outlines the meaning behind selectivity and highlights how to leverage selectivity in data centre design.
What is Selectivity?
Selectivity is achieved by carefully coordinating the time-current characteristics (TCC) of the protective devices in the system. The TCC curves show how long a protective device takes to respond to a given level of fault current. By ensuring that downstream devices (closer to the fault) have faster response times than upstream devices, selectivity is maintained.
There are two main types of selectivity:
- Time-based selectivity: This relies on ensuring that the protective devices at different levels of the distribution system have different response times. For instance, a fuse near the fault may be set to respond more quickly than a circuit breaker further upstream. This ensures that only the faulty section is isolated, while power remains available to the rest of the system.
- Current-based selectivity: In some cases, protective devices can be coordinated based on the level of fault current. For example, a device downstream may trip at a lower current threshold than one upstream. This type of selectivity is particularly important in systems where the time difference alone may not be sufficient to guarantee proper isolation.
Importance of Selectivity in Data Centres
Minimising Data Centre Downtime:
In data centres, even a brief power outage can have significant financial and operational consequences. Proper selectivity ensures that only the section of the system directly affected by the fault is disconnected, allowing the rest of the data centre to remain operational. This minimises disruptions and helps ensure high levels of uptime.
Protecting Sensitive Equipment:
Data centres house sensitive equipment, such as servers and cooling systems, that need a stable power supply to function properly. If selectivity is not properly implemented, a fault in one area of the system could cause protective devices to trip unnecessarily, cutting power to critical equipment and potentially causing data loss or system failures.
Improving Data Centre Safety:
Selectivity plays a crucial role in improving safety in a data centre environment. By ensuring that faults are quickly and accurately isolated, the risk of electrical fires, explosions, or other dangerous conditions is reduced. Furthermore, this minimises the likelihood of cascading failures that could jeopardise the safety of personnel working in or near the data centre.
Cost Efficiency:
Proper selectivity can reduce the cost of repairs and maintenance. Isolating a fault to the smallest possible section of the system helps prevent widespread damage to equipment and infrastructure, making it easier and more cost-effective to identify and repair faults.
Compliance with Legal and Operational Requirements:
Data centres must adhere to strict safety and reliability standards, such as IEEE 242 and NFPA 70E, which outline guidelines for protective device coordination. Proper selectivity ensures compliance with these regulations, helping data centres meet legal and operational requirements.
Techniques and Standards We Follow for Selectivity
Industry Standards: We adhere to globally recognised standards such as IEEE 242 and IEEE 399 for protective device coordination. These standards ensure that all protective devices in the system – like relays, fuses, and circuit breakers – respond appropriately to fault conditions, thus preventing widespread outages and ensuring safety.
ETAP’s Star™ Module: Using ETAP’s Star™ Protective Device Coordinationmodule, we accurately model the electrical system and simulate fault scenarios. This allows us to fine-tune the settings of protective devices for optimal coordination, ensuring that only the device closest to the fault trips, minimizing the impact on the overall system.
Time-Current Characteristic (TCC) Curve Analysis: A key aspect of our selectivity studies is TCC curve analysis, which visually represents the response times of various protective devices. ETAP’s advanced TCC plotting tools help us ensure precise coordination between devices, ensuring that they respond in the correct order. This minimizes unnecessary disruptions in other parts of the system and ensures compliance with industry standards like IEEE and NFPA 70E
Compliance with Safety Standards: Our selectivity studies using ETAP are fully compliant with IEEE 1584, NFPA 70E, and other international standards, ensuring the highest level of safety and reliability in the electrical system.
How ETAP Standards Enhance Safety
Using ETAP for selectivity and coordination studies offers several safety benefits:
- Accurate Fault Simulation: ETAP allows us to simulate a wide range of fault conditions, ensuring that the system reacts as expected during real-world scenarios. This simulation capability helps in verifying whether protective devices are correctly configured to isolate only the faulty section, keeping the rest of the system operational.
- Protective Device Coordination: With the Star™ Auto-Evaluation feature, ETAP automatically checks the coordination of protective devices, ensuring that they are optimized to work together. This coordination minimizes unnecessary equipment downtime, enhances system reliability, and reduces maintenance costs.
- Compliance and Reporting: ETAP generates comprehensive reports that document the settings of each protective device, ensuring compliance with industry safety standards like NFPA 70E and IEEE 1584. These reports are invaluable for routine audits and system maintenance.
Leveraging Selectivity in Data Centre Design
Data centres are highly sensitive environments where uptime is critical, and even minor disruptions can lead to significant financial losses. By conducting selectivity studies during the design phase, we ensure that protective devices are strategically placed and properly coordinated. ETAP’s extensive library of protective devices allows us to accurately simulate various configurations and identify potential areas of improvement.
For example, ETAP enables us to:
Model Complex Systems:
We can simulate entire electrical networks, including multiple layers of protection for each system component. This helps in determining the most efficient way to isolate faults without impacting the rest of the data centre.
Optimise Device Settings for Best Performance:
Using ETAP’s TCC curves, we can fine-tune device settings, ensuring optimal performance under different fault conditions. This reduces unnecessary tripping of upstream devices and keeps the critical infrastructure running.
Improvement Through Simulation:
ETAP allows us to run “what-if” scenarios, which help in predicting the behaviour of the system under varying load conditions. This flexibility helps us refine the design, making it more resilient to faults while maintaining operational integrity.
Customised Solutions for Your System’s Needs
If the client already has device settings: We can use ETAP to perform a detailed analysis based on the provided settings. Our team can generate reports that show whether the current settings ensure proper selectivity or if adjustments are needed. This is ideal for clients who want to verify the effectiveness of their existing configurations.
If the client does not have device settings: If settings are not available or if the system is being newly designed, we can conduct a comprehensive study using ETAP. Based on the results, we will recommend the correct settings for protective devices—whether they are new installations or existing devices needing reconfiguration. This ensures that the system will operate efficiently, minimizing the risk of unnecessary shutdowns and maximizing safety and uptime.
Conclusion
At Future-tech, we integrate cutting-edge software like ETAP to enhance the safety and reliability of our data centre designs. By conducting thorough selectivity studies and adhering to industry standards, we ensure that protective devices are perfectly coordinated, reducing downtime and preventing widespread outages. ETAP’s advanced tools, such as Star™ Auto-Evaluation and TCC analysis, enable us to deliver highly efficient and safe electrical systems that meet the unique demands of data centres. Our approach not only safeguards equipment and personnel but also ensures uninterrupted service, which is vital for data centre operations.
Get in touch with our team of expert engineers today to find out more.
